Tolerance is a set of measures or other physical characteristics that allow a thing to perform properly and/or seem visually attractive. In most circumstances, tolerance refers to a product’s lowest or maximum measurement range in X, Y, and Z dimensions. Tolerance can also be expressed in terms of colour, texture, form, or profile.

For example, if you design a product with geometric elements, such as holes in a component, the manufacturer will need to know specific tolerance parameters before they can construct the part, such as

  • The nominal diameter of the hole—can it be smaller or bigger in the finished product, and if so, how much larger or smaller before affecting essential functionality?
  • What is the exact location of the hole in X, Y, and Z dimensions—how much variation in placement is permitted for the part to work properly?

The more exact these calculations are, the easier it will be to build the product. Tolerances are significant in manufacturing for this reason. Defining them provides you more control over your goods’ consistency, accuracy, precision, and quality.

What Is the Importance of Tolerances in Manufacturing?

Almost every product has a feature that must be managed using tolerance measures. Tolerances are significant in manufacturing for six major reasons:

  1. They increase part fit and functionality: Tolerances must be defined if you are constructing parts that are compatible with other components. Even minor miscalculations or differences in size might render your product functionally ineffective or incompatible.
  2. They improve the final product’s appearance: If aesthetics are important to you, tolerances should be as well. For example, if you want a part to sit flat against another part with no visible space between them, you must carefully regulate the dimensions and placements of both pieces.
  3. You can account for a fair level of mistake: Tolerances allow for some inaccuracy, but only to the degree that the part remains functioning. When you set your tolerances from the beginning, you reduce the likelihood of having to recreate pieces later.
  4. Manufacturing is less expensive: When tolerances are defined, a product is only as accurate as it needs to be. This means you’ll only spend for the materials, manufacturing tools, and labour required to get the desired outcome.
  5. You’ll get your items to market faster: Although it takes a bit longer to figure out the tolerances at first, this extra step saves you time in the long run. Mismeasurements and inconsistencies in products can cause your time to market to be delayed by weeks or even months as you wait for replacement components to be manufactured.
  6. Tolerances decrease manufacturing ambiguity and complexity: Ambiguity is manufacturing’s worst enemy. If you don’t clarify what you want, you can wind up with something you can’t utilise. Tolerances eliminate any uncertainty in the equation. Tolerances also make life easier for producers. For example, if your product does not require accuracy to within 0.002mm, there is no reason for manufacturing to break their backs attempting to reach this high degree of precision.
